|Reduction Ratio||3.56, 4.13, 4.59|
|Max. Input torque [kg.m]||298, 292, 286|
|Max. Input (rpm)||2300|
|Power/rpm (HP)||0.410, 0.402, 0.394|
|Dry weight (kg)||764|
|Engine power (Hp, 1800 rpm)||738, 723, 710|
|Engine power (Hp, 2100 rpm)||862, 845, 828|
|Engine power (Hp, 2300 rpm)||943, 926, 907|
Reverse reduction type with hydraulically actuated multi disc clutches.
Cast-iron case, vertical off set and direct mounting.
Same torque capacity & ratio in both ahead and astern
Easy maintenance & robust design.
Precisely ground gear teeth for long life and smooth operating.
"Go home" function in emergency.
Various applications : for pleasure, light, medium and contiuous duty.
SAE #1, and SAE #0 bell housings .
Engine-matched Rubber Block type coupling .
Oil cooler Assembly
Mounting brackets(Plate Type for welding) .
Propeller shaft flange .
Control cable bracket and Clamp parts for connection of the push-pull cable .
CENTA Flexible Coupling
Trolling valve for slow speed navigation
Electric shifting valve
